Name: UL 94 V-0 Certified Crystal Clear Epoxy Potting Resin with Room-Temperature Cure for Electrical Transformers
Brand: Shanghai Wenyou Industry Co., Ltd.
SKU: 8218a
Price: 2.60 USD
Availability: InStock

집 > 상품 > 난연성 에폭시 수지 >

UL 94 V-0 Certified Crystal Clear Epoxy Potting Resin with Room-Temperature Cure for Electrical Transformers

Crack-resistant epoxy resin for transformers

Flame retardant epoxy resin insulation

Dry-type transformer epoxy resin coating

원래 장소:

중국

브랜드 이름:

wenyou

인증:

ISO9001, ISO14001, SGS, and UL

모델 번호:

8218a

연락주세요

인용문을 요구하세요

제품 상세정보

분류:

이중 구성물 접착제

용법:

절연제품, 커넥터 등

애플리케이션:

상온 경화된 다양한 제품

에폭시 수지의 외관:

붉은 점성 액체

40' Ｃ에 있는 점착성:

20000-40000mpa.s

25°C에서의 밀도:

1.55 - 1.70g/cm3

25°C에서의 증기압:

< 0.01Pa

인화점:

약 135' Ｃ

기술:

전자 커넥터 결정 맑은 에포시 樹脂 수동 붓는 경화제

지불과 운송 용어

최소 주문 수량

샘플로 20kg/통

가격

협상 가능

포장 세부 사항

20kg/통, 220kg/배럴, 1200kg/탱크

배달 시간

7 -10 근무일

지불 조건

일반적으로 t/t, l/c

공급 능력

재고가 많은 원자재

맑은 발사 방화 retardant 에포시 樹脂 액체 접착제 APG 프로세스 TG 115-128 전기 단열

최상의 가격을 얻으세요

Flame Retardant Epoxy Resin Potting Compound with Alicyclic Saturated Structure Light Yellow Color and Excellent Environmental Performance

최상의 가격을 얻으세요

130-150°C 금형 온도 및 10-30분 겔화 시간을 갖는 전기 절연 부품용 난연성 APG 에폭시 수지

최상의 가격을 얻으세요

고 TG (70-125 °C) 및 APG 및 발사 공정을위한 10-1100KV 전기 단열을위한 불 retardant 에포시 樹脂

최상의 가격을 얻으세요

연락주세요

008618018933365

Elliot.yang@sh-wysy.com

86-21-64308192

지금 접촉하세요

제품 설명

UL 94 Flammability V-0 Fire-Resistant Epoxy Potting Resin for Electrical Transformers & Coils

LW-8128A/LH-8116: UL 94 V-0 Crystal Clear Epoxy Potting Resin for Electronic Connectors | Hand-Pour Application

Product Overview

LW-8128A/LH-8116 is a premium two-component, crystal clear epoxy potting system engineered for hand-pour encapsulation of sensitive electronics. Featuring UL 94 V-0 flame resistance, modified PBA epoxy resin (LW-8128A), and a modified amine hardener (LH-8116), this system delivers exceptional clarity, electrical insulation, and fire safety for electronic connectors, sensors, and micro-transformers. With room-temperature curing and vacuum-compatible processing, it ensures bubble-free protection against moisture, chemicals, and thermal stress.

Key Features & Benefits

Property	Specification	Benefit
Flame Resistance	UL 94 V-0 Certified	Prevents fire propagation in electrical failures
Clarity	Crystal Clear (Custom Color Options)	Aesthetic transparency for visual inspection of components
Curing	Room-Temperature Cure	Energy-efficient processing; no ovens required
Processing	Hand-Pour or Vacuum Casting	Flexible for low-volume batches or precision vacuum impregnation
Electrical Safety	High Dielectric Strength	Reliable insulation for connectors operating under electrical stress
Compatibility	Pre-Mixed Fillers & Color Paste	Uniform consistency; reduces mixing errors

Applications

Ideal for encapsulating:

Electronic connectors (signal, power, PCB headers)
Miniature transformers and inductors
Sensor modules and LED arrays
Insulation bobbins and coil terminals
Wearable electronics and IoT devices

Technical Specifications

Epoxy Resin	LW-8128A (100 pbw)
Curing Agent	LH-8116 (20-25 pbw)
Color Paste	LC Series (1 pbw, optional)
Viscosity	Paste Consistency (25°C)
Pot Life	40-60 minutes (25°C)
Cure Time	24-48 hours (25°C)
Hardness (Shore D)	≥85
Certification	UL 94 V-0 Flame Rating

Processing Guide

Mixing: Blend LW-8128A resin and LH-8116 hardener at 100:22.5 pbw (default ratio). Add LC-series color paste if required.
Degassing: Vacuum degas mixture (recommended for bubble-free clarity).
Pouring: Hand-pour or gravity-cast over components.
Curing: Cure 24h at 25°C (accelerated curing at 60°C optional).

Why Choose This System?

Flame Safety: Meets stringent UL 94 V-0 standards for electronics in high-risk environments
Ease of Use: Paste consistency simplifies manual application without sagging
Optical Clarity: Maintains component visibility for QC inspections
Adaptable: Integrates with existing hand-pour or vacuum production lines
